Pressure sensor mat

MobileMat

An attractive, lightweight, & durable mat for static & dynamic pressure assessment on the field, in the office or in the lab.

Not available for online purchase.
Contact us for pricing

Description

Pressure Sensor Mat

The MobileMat™ is Tekscan's standard resolution portable pressure mat. Combined with Tekscan's innovative software, the mats can be used for a variety of applications to capture and evaluate static and dynamic foot function, profile anatomical landmarks, assess postural stability, and perform balance and sway analysis.

MobileMat™ Features

The MobileMat is light-weight and durable making it easy to transport.The MobileMat is light-weight and durable making it easy to transport.

  • Stylish, low profile mat - platform height at the sensing area is only 0.3 in. (0.76 cm)
  • Portable and durable with virtually no set up time
  • Quick and easy with USB connection
  • Simple and easy-to-use
  • Available with Evolution™ electronics - Scanning speed of up to 100 Hz
  • Provides objective and quantifiable pressure data
  • Slim, convenient design with handle
  • Collect data wherever and whenever you want in minutes

Choice of Software for Specific Applications

  • SportsAT™ - software includes essential balance tools and standardized concussion test protocols, including Balance Error Scoring System (BESS) and Sports Concussion Assessment Tool (SCAT3™).
  • FootMat™ Software for Clinicians - for analyzing foot function and gait.
  • FootMat™ Software for Researchers - contains added features specific to research applications (for example: the ability to export to Excel, ASCII and MATLAB®).

SportsAT Software automates the Balance Error Scoring System (BESS) for more objective results.SportsAT Software automates the Balance Error Scoring System (BESS) for more objective results.

FootMat Software 3-Box protocol. Click to enlarge.FootMat Software 3-Box protocol. Click to enlarge.

Applications

The Applications are Endless

The MobileMat can be used for many different applications including patient education.The MobileMat can be used for many different applications including patient education.

  • Reduce incidence of ulcers and/or pressure sores by observing what the neuropathic foot cannot feel
  • Provide supporting documentation for fee-for-service and/or insurance claims
  • Use as an educational tool to teach rehabilitation exercises for the lower limb
  • Identify plantar pressure profile asymmetries between left and right feet
  • Perform in-depth analysis of foot function by isolating sections of the foot such as the heel, mid-foot, and forefoot
  • Baseline and concussion assessment testing
  • Review dynamic weight transfer and local pressure concentrations
  • Identify areas of potential ulcerations
  • Monitor improvements in balance, strength & weight bearing

Numerous articles have been published regarding computerized gait analysis and its applications. Tekscan has compiled a list of these research publications in our Medical Bibliography.





Application Flyers

Choose from the list of flyers below to learn more about the different applications possible with our products:

Concussion Assessments

Foot Function

Balance & Stability

Configuration

Components

The MobileMat™ system includes the sensor platform, scanning electronics and a choice of software: FootMat™ Software for Clinicians or SportsAT™. Evolution™ electronics are included internally. The MobileMat connects to a computer via USB port.

MobileMat SystemMobileMat System

Additional items may be included with your system purchase.

Sensors

MobileMat™ Pressure Sensors

  • Resistive technnology
  • Sensing area is 48.7 x 44.7 cm (19.2 x 17.6 in.)
  • Pressure range is 125 psi/862 kPa
  • Floor mat height at the sensing area is 0.3 in. (0.76 cm)

Software

Compatible Software

The MobileMat™ platform supports the full suite of Tekscan software applications for foot function, gait, peak plantar pressure, weight distribution, stance timing, balance and sway analysis, and concussion assessments.

The price of the mat includes one of the following software:

FootMat Software for Clinicians generates comprehensive reports.FootMat Software for Clinicians generates comprehensive reports.

FootMat™ Software for Clinicians: Collects static and dynamic pressure data for analyzing foot function and gait. Software includes automated analysis and reporting.

FootMat Software showing 3-Box foot parameters table.FootMat Software showing 3-Box foot parameters table.

FootMat Software for Researchers: Contains the same core features as the FootMat Software for Clinicians but has added features for a more detailed analysis. Including data export capabilities (ASCII, AVI, Excel, MATLAB®), additional calibration points and the ability to synchronize with external devices. (Additional charges apply.)

SCAT3 sample report.SCAT3 sample report.

SportsAT™: software includes essential balance tools and standardized concussion test protocols, including Balance Error Scoring System (BESS) and Sports Concussion Assessment Tool (SCAT3™).

All Tekscan software works with current Windows® based operating systems. To view the complete computer requirements click here.

The software is available in several languages including Spanish, French and German. View software languages available.

Add-ons

Add-Ons

Optional add-on protocols and software can be purchased for an additional cost. A software development kit is also available that enables you to build your own applications.
