What is FootMat Software for Researchers?

FootMat™ Software for Researchers uses Tekscan's pressure measurement platforms to collect accurate and reliable pressure data for analyzing foot function and gait. Perform a complete foot analysis by capturing static pressure data or dynamic pressure data of multiple steps for gait assessments.


Calibrate the platforms specifically to meet your needs, there is no need to send the system back to the factory for calibration Pressure measurement platform is used by leading researchers around the world Focused software for foot function and gait analysis	Data export capabilities for a more detailed analysis include Excel, ASCII, MATLAB Evaluate data in frame by frame, single or multi-stance phase modes	Synchronize with external systems, like motion capture, EMG and force plates for a more complete picture Remote triggering option allows you to synchronize the start and stop of data collection with Tekscan and other gait lab systems	3-box analysis: Segment the foot into three regions for deeper analysis Peak pressure analysis: Identifies and quantifies peak pressures

FootMat Software for Researchers Applications Include:

Identify plantar pressure profile asymmetries between left and right feet
Perform in-depth analysis of foot function
Review dynamic weight transfer and local pressure concentrations
Evaluate center of force (CoF) movement

Identify asymmetries during stance phase
Study peak pressures on the plantar surface
Evaluate biomechanical pivot phases of the foot (heel, ankle, forefoot)

Tekscan's Pressure Measurement Platforms

FootMat™ Software uses Tekscan’s pressure measurement platforms to collect accurate and reliable pressure data for studying foot function and gait.

The software runs on the following pressure measurement mats:

Pressure sensing mat that captures static and dynamic pressure measurement data. Easily transported for use on the field, in the lab or almost anywhere. Also in MobileMat HR version - High-resolution floor mat designed to capture plantar pressure and forces for both children and adults.

Learn more

Software

FootMat™ Software for Researchers provides accurate pressure data for studying foot function and gait with added features specific to research applications.

All Tekscan software works with current Windows-based operating systems. To view the complete computer requirements click here.

The software is available in several languages including Spanish, French and German. View available software languages.

Key Software Features Include:

Automated analysis & report generation
Ability to segment areas of the foot for a more detailed analysis
2D and 3D display for real-time and recorded data
Display pressure and force curves over time
Side-by-side comparisons of pre- and post-treatment conditions
Graph for force-time integrals (Impulse)

Frame by frame, single, and multi-stance phase displays
Import and export client movie files
Display the center of force and its trajectory
Analyze data for asymmetries in pressure distribution, deviations in the center of force trajectory and weight bearing
Foot function parameter tables display information on contact time, loading and off-loading rates and center of force (CoF) velocity information for in-depth analysis
